STB with GPON/EPON Access
IP106H-F/IP206H-F
The ONT&IPTV/OTT Fusion all-in-one is a converged intelligent network set-top box terminal launched by Hisense for the increasingly popular FTTH scenario. This series of products with both Home Gateway (HGU) and Intelligent Set Top Box (IPTV) capabilities will become the core terminal devices for smart homes. It adopts innovative design and PON access function; it adopts modular and universal design concept to realize the combination of different technical solutions. It can integrate rich and customized business.
ADD TO CARTGPON/EPON ONT Router combined with 4K UHD IPTV/OTT STB
IEEE 802.11b/g/n MIMO 2*2 2.4GHz
One Port 1000Base-T(GE) + One Port 100Base-T(FE)
Econet EN7526 SoC for ONT
Quad-core Amlogic S905L2 SoC for IPTV/OTT STB
Support HDMI 2.0
H.265 HEVC decoding up to 4K*2K@60fps
Android OS to provide ability to install APPs as requested
Support Dolby Digital and Dynamic HDR10, HDR10+, HLG
Support RTSP, RTP, RTCP, HLS streaming media protocol
Support DLNA Multi screen interactive protocol
Support 2.488Gbps downstream data rate and 1.244 Gbps upstream data rate
Providing one POTS port with VOIP, users can make or receive phone calls
Support 802.11 b/g/n standard WiFi access
Support IGMP v2/3, IPv4/6 Dual Stack
Support multiple internet modes, DHCP/PPPOE/Static IP/Bridge WAN
Support port forwarding and L3 routing
Support the ONT management and Control Interface OMCI and TR069 network management
