PRODUCTS

Optical Communication Terminal Devices

ACCESS
NGPON 2 XGPON/XGSPON 10G EPON GPON BiDi/CSFP CPON 25G SPON 50G PON 50G CPON
DATA CENTER
Fiber Channel Ethernet Optical Interconnection Data Center Interconnection
TELECOM
SFP SFP+ SFP28 XFP QSFP28 QSFP-DD
WIRELESS
3G/4G Wireless Network 5G Wireless Network Fronthaul 5G Wireless Network Middlehaul&Backhaul

ACCESS

NGPON 2

+View Full Product List
Picture Product Name Part Number Package Interface Reach Temp Tx Output Tx Rate Tx Wavelength Rx Input Rx Rate Rx Wavelength
NG-PON2 OLT Class N2 LTW627XB-PCA+ XFP SC/UPC 20km C 7.2~10.2dBm 9.953Gb/s 1596.34/1597.19/
1598.04/1598.89nm		 -30.1dBm 9.953Gb/s 1524~1544nm
+View Full Product List

XGS PON

+View Full Product List
Picture Product Name Part Number Package Interface Reach Temp Tx Output Tx Rate Tx Wavelength Rx Input Rx Rate Rx Wavelength
XGS-PON OLT Class E1 LTF7226B-BCB+
LTF7226B-BHB+		 SFP+ SC/UPC 20km C, H 6~9dBm 9.953Gb/s 1577nm -30dBm
-31.5dBm		 9.953Gb/s
2.488Gb/s		 1270nm
XGS-PON OLT Class N2 LTF7226B-BCA+
LTF7226B-BHA+		 SFP+ SC/UPC 20km C, H 4~7dBm 9.953Gb/s 1577nm -28dBm
-29.5dBm		 9.953Gb/s
2.488Gb/s		 1270nm
XGS-PON ONU LTF7225-BCA+
LTF7225-BHA+		 SFP+ SC/APC 20km C, H 4~9dBm 9.953Gb/s 1270nm -28dBm 9.953Gb/s 1577nm
+View Full Product List

10G EPON

+View Full Product List
Picture Product Name Part Number Package Interface Reach Temp Tx Output Tx Rate Tx Wavelength Rx Input Rx Rate Rx Wavelength
10G EPON ONU LTF7215-BC+ SFP+ SC/UPC 20km C 0.62~5.62dBm 1.25Gb/s 1310nm -28.5dBm 10.3125Gb/s 1577nm
10G EPON ONU LTF7219-BCA+
LTF7219-BHA+		 SFP+ SC/APC 20km C,H 4~9dBm 10.3125Gb/s 1270nm -28.5dBm 10.325Gb/s 1577nm
10G EPON OLT PR40 LTF5302-BCA+ SFP+ SC/UPC 20km C 5~9dBm
4~10dBm		 10.3125Gb/s
1.25Gb/s		 1577nm
1490nm		 -29dBm
-32dBm		 10.3125Gb/s
1.25Gb/s		 1270nm
1310nm
+View Full Product List

GPON

+View Full Product List
Picture Product Name Part Number Package Interface Reach Temp Tx Output Tx Rate Tx Wavelength Rx Input Rx Rate Rx Wavelength
GPON OLT Class D LTE3680P-BC+4 SFP SC/UPC 20km C 6~10dBm 2.488Gb/s 1490nm -33dBm 1.244Gb/s 1310nm
GPON OLT Class C++ LTE3680P-BC+2
LTE3680P-BH+2		 SFP SC/UPC 20km C,H 4.5~10dBm 2.488Gb/s -30dBm 1.244Gb/s
GPON OLT Class B+ LTE3680M-BC+
LTE3680M-BH+		 SFP SC/UPC 20km C,H 1.5~5dBm 2.488Gb/s 1490nm -28dBm 1.244Gb/s 1310nm
+View Full Product List

BiDi/CSFP

+View Full Product List
Picture Product Name Part Number Package Interface Reach Temp Tx Output Tx Rate Tx Wavelength Rx Input Rx Rate Rx Wavelength
25G BIDI LTF2325-BH+ SFP28 LC 10km H -4~2.2dBm 25.78Gb/s 1270nm -12dBm 25.78Gb/s 1330nm
25G BIDI LTF3225-BH+ SFP28 LC 10km H -4~2.2dBm 25.78Gb/s 1330nm -12dBm 25.78Gb/s 1270nm
25G BIDI LTF2328-BH+ SFP28 LC 40km H 0~6dBm 25.78Gb/s 1270nm -18.5dBm 25.78Gb/s 1310nm
+View Full Product List

CPON

+View Full Product List
Picture Product Name Part Number Package Interface Reach Temp Tx Output Tx Rate Tx Wavelength Rx Input Rx Rate Rx Wavelength
XGS-PON/GPON Combo OLT
Class D		 LTF5308B-BCE+
LTF5308B-BHE+		 SFP+ SC 20km C,H 8~11dBm
6~10dBm		 9.953Gb/s
2.488Gb/s		 1577nm
1490nm		 -32dBm
( BER@10-3) -33.5
(BER@10-4)
-33dBm
( BER@10-3) -35
(BER@10-4)		 9.553/2.488Gb/s
1.244Gb/s		 1270nm
1310nm
XG-PON/GPON Combo OLT
Class C+		 LTF5306-BCC+ SFP+ SC 20km C 5~9dBm
4.5~8.5dBm		 9.953Gb/s
2.488Gb/s		 1577nm
1490nm		 -30.5dBm
-30dBm (BER@10ˉ10) -32dBm (BER@10ˉ4)		 2.488Gb/s
1.244Gb/s		 1270nm
1310nm
XGS-PON/GPON Combo OLT
Class N2/C+		 LTF5308B-BCA+
LTF5308B-BHA+		 SFP+ SC 20km C,H 4~7dBm
3~7dBm		 9.953Gb/s
2.488Gb/s		 1577nm
1490nm		 -26dBm
( BER@10-3) -27.5
(BER@10-4)
-28dBm
( BER@10-3) 29.5
(BER@10-4)		 9.553/2.488Gb/s
1.244Gb/s		 1270nm
1310nm
+View Full Product List

25G SPON

+View Full Product List
Picture Product Name Part Number Package Interface Reach Temp Tx Output Tx Rate Tx Wavelength Rx Input Rx Rate Rx Wavelength
25GSPON ONU LTF7605-BH+ SFP28 SC/UPC 20km H 4.78dBm 25.78125/24.8832/
9.953/10.3125Gb/s		 1300nm -24.9dBm 25.78125/24.8832Gb/s 1358nm
25GSPON OLT Class N2 LTF6703-BCA+ SFP28 SC 20km C 9dBm 24.8832Gbps Gb/s 1358nm -26.3dBm
-28dBm		 25.78125Gbps/24.8832Gbps 1260~1310nm
25GSPON OLT Class N1 LTF6703-BC+
LTF6703-BH+		 SFP28 SC 20km C 4.1~7.8dBm 25.78125Gbps/
24.8832Gbps		 1358nm -24.3dBm 25.78125Gbps/
24.8832Gbps		 1260~1310nm
+View Full Product List

50G PON

+View Full Product List
Picture Product Name Part Number Package Interface Reach Temp Tx Output Tx Rate Tx Wavelength Rx Input Rx Rate Rx Wavelength
50G GPON ONU LTQ3402-PC+ QSFP112 SC 20km C 2dBm 24.8832 Gb/s 1284nm~1288nm -21dBm 49.7664 Gb/s 1340nm~1344nm
50G GPON ONU LTQ3401-PC+ QSFP112 SC 20km C 2dBm~ 24.8832 Gb/s 1290nm~1310nm -21dBm 49.7664 Gb/s 1340nm~1344nm
50G GPON OLT LTQ4301-PC+ QSFP112 SC 20km C 2dBm 49.7664 Gb/s 1340nm~1344nm -24.5dBm 24.8832/12.5 Gb/s 1260~1310nm
+View Full Product List

50G CPON

+View Full Product List
Picture Product Name Part Number Package Interface Reach Temp Tx Output Tx Rate Tx Wavelength Rx Input Rx Rate Rx Wavelength
50G&10G&GEPON Combo OLT
(Narrow Band)		 LTQ5607-PC+ QSFP-DD SC 20km C 5.5dBm
2~5dBm
2~7dBm		 49.7664Gb/s
10.3125Gb/s
1.25Gb/s		 1340~1344nm
1575~1580nm
1490nm		 -24.5dBm
-26dBm
-28dBm		 24.8832 Gbp/s
10.3125Gb/s
1.25Gb/s		 1284nm~1288nm
1260~1280nm
1310nm
50G&XGS&GPON Combo OLT LTQ5606-PC+ QSFP-DD SC 20km C 5.5dBm
2~5dBm
1.5~5dBm		 49.7664Gb/s
9.953Gb/s
2.488Gb/s		 1340~1344nm
1575~1580nm
1490nm		 -24.5dBm
-26dBm
-28dBm		 24.8832 Gbp/s
9.953 Gb/s
1.244Gb/s		 1284nm~1288nm
1260~1280nm
1310nm
50GPON&10G EPON Combo OLT LTQ5307-PC+ QSFP-DD SC 20km C 5.5dBm
2~5dBm		 49.7664Gb/s
10.3125Gb/s		 1340~1344nm
1577nm		 -24.5dBm
-28dBm		 24.8832 Gbp/s
10.3125Gb/s		 1286nm
1260~1280nm
+View Full Product List

DATA CENTER

Fiber Channel

+View Full Product List
Picture Part Number Package Interface Reach Temp Fiber Type Wavelength Rate Tx Output Rx Input
LMF8051 SFP56 LC 150m C Single-mode 850nm 64G - -
LMF3058 SFP56 LC 10km C,E Single-mode 1310nm 64G - -
LTF1335 SFP28 LC 10km C,E Single-mode 1310nm 32G - -
+View Full Product List

Ethernet

+View Full Product List
Picture Part Number Package Interface Reach Temp Fiber Type Wavelength Rate Tx Output Rx Input
LMS3831 OSFP MPO 500m C Single-mode 1310nm 1.6T(8*200G) - -
LMS3631 OSFP MPO 2km C Single-mode 1310nm 800G(4*200G) - -
LMS3636 OSFP MPO 2km C Single-mode 1271nm
1291nm
1311nm
1331nm		 800G(4*200G) - -
+View Full Product List

Optical Interconnection

+View Full Product List
Picture Part Number Package Interface Reach Temp Fiber Type Wavelength Rate Tx Output Rx Input
DMS8821 OSFP Cable 1~50m C Single-mode 850nm 800G(8*100G) - -
DME8821* OSFP Cable 1~50m C Single-mode 850nm 800G(8*100G) - -
DME3821* OSFP Cable 1~50m C Single-mode 850nm 800G(8*100G) - -
+View Full Product List

TELECOM

SFP

+View Full Product List
Picture Part Number Package Interface Reach Temp Fiber Type Wavelength Rate Tx Output Rx Input
LTD1305-BC+
LTD1305-BH+		 SFP LC 15km C,H Single-mode 1310nm 2488Mb/s -5~0dBm -21dBm
LTD1302-BC+
LTD1302-BH+		 SFP LC 10km C,H Single-mode 1310nm 1.25Gb/s -9.5~-3dBm -21dBm
+View Full Product List

SFP+

+View Full Product List
Picture Part Number Package Interface Reach Temp Fiber Type Wavelength Rate Tx Output Rx Input
LTF7226B-BC+
LTF7226B-BH+
LTF7226B-BCA+
LTF7226B-BHA+
LTF7226B-BCB+
LTF7226B-BHB+
LTF7226B-BCC+
LTF7226B-BHC+		 SFP+ SC 20km
40km
60km		 C, H 2~5dBm
2~5dBm
4~7dBm
4~7dBm
6~9dBm
6~9dBm
8~11dBm
8~11dBm		 -26dBm
-26dBm
-28dBm
-28dBm
-30dBm
-30dBm
-32dBm
-32dBm
-27.5dBm
-27.5dBm
-29.5dBm
-29.5dBm
-31.5dBm
-31.5dBm
-33.5dBm
-33.5dBm
LTF1502-BC1
LTF1502-BH1		 SFP+ LC 80km C,H Single-mode 1550nm 10Gb/s 0~4dBm -24dBm
LTF1502-BC+
LTF1502-BH+		 SFP+ LC 80km C,H Single-mode 1550nm 10Gb/s 0~4dBm -24dBm
+View Full Product List

SFP28

+View Full Product List
Picture Part Number Package Interface Reach Temp Fiber Type Wavelength Rate Tx Output Rx Input
+View Full Product List

XFP

+View Full Product List
Picture Part Number Package Interface Reach Temp Fiber Type Wavelength Rate Tx Output Rx Input
LTW627XB-PCA+ XFP SC/UPC 20km C 7.2~10.2dBm -30.1dBm
+View Full Product List

QSFP28

+View Full Product List
Picture Part Number Package Interface Reach Temp Fiber Type Wavelength Rate Tx Output Rx Input
LTA1335C -PC1 QSFP28 LC 10km C Single-mode LAN-WDM 200Gb/s -4.3dBm~4.5dBm -8.6dBm(OMA)
LTA1335C-PC+ QSFP28 LC 10km C Single-mode LAN-WDM 200Gb/s -4.3dBm~5.5dBm -8.6dBm(OMA)
LMQ3327-PC+ QSFP28 LC 40km C Single-mode 1310nm 100Gb/s 0~5.6dBm -14.7dBm
+View Full Product List

200G QSFPDD

+View Full Product List
Picture Part Number Package Interface Reach Temp Fiber Type Wavelength Rate Tx Output Rx Input
LTA1335 QSFP-DD CS 10km C Single-mode 1310nm 200Gb/s -4.3~4.5 -8.6
+View Full Product List

WIRELESS

3G/4G Wireless Network

+View Full Product List
Picture Part Number Package Interface Reach Temp Fiber Type Wavelength Rate Tx Output Rx Input
LTF8502-BC1
LTF8502-BH1		 SFP+ LC 300m C,H Multi-mode 850nm 9.83Gb/s -7.3~-1dBm -11.1dBm
LTF1303-BC+
LTF1303-BH+		 SFP+ LC 1.4km C,H Single-mode 1310nm 9.83G -8.2~0.5dBm -14.4dBm
LTF1305-BC+
LTF1305-BH+		 SFP+ LC 10km C,H Single-mode 1310nm 9.83Gb/s -8.2~0.5dBm -14.4dBm
+View Full Product List

5G Wireless Network Fronthaul

+View Full Product List
Picture Part Number Package Interface Reach Temp Fiber Type Wavelength Rate Tx Output Rx Input
LTF2325-BH+ SFP56 LC 10km C single-mode 1271nm
1291nm
1311nm
1331nm
1351nm
1371nm		 50Gb/s -4.5~4.2dBm -8.9dBm(OMA)
LTF3228-BH+ SFP28 LC 40km H single-mode 25.78Gb/s 1310nm -18.5dBm 25.78Gb/s
LTF2328-BH+ SFP28 LC 40km H single-mode 25.78Gb/s 1270nm -18.5dBm 25.78Gb/s
+View Full Product List

5G Wireless Network Middlehaul&Backhaul

+View Full Product List
Picture Part Number Package Interface Reach Temp Fiber Type Wavelength Rate Tx Output Rx Input
LMQA32DB-PC+
LMQB32DB-PC+		 QSFP28 LC 30km C single-mode 1304nm
1309nm		 100Gb/s 0~5.6dBm -14.7dBm
LMQ7328B-PC+
LMQ2328B-PC+		 QSFP28 LC 10km C single-mode 1271nm
1331nm		 100Gb/s -1.9~4.8dBm -8.2dBm
LMQ3118W QSFP28 QSFP28 LC 10km C single-mode 1310nm 50Gb/s -4.5~4.2dBm -8.9dBm(OMA)
+View Full Product List
